<!--DataGrid -->
<!--Style and template for the resize control on the DataGridColumnHeader.-->
<Style x:Key="ColumnHeaderGripperStyle" TargetType="{x:Type Thumb}">
<Setter Property="Width" Value="5" />
<Setter Property="Background" Value="Transparent" />
<Setter Property="Cursor" Value="SizeWE" />
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type Thumb}">
<Border Background="{TemplateBinding Background}" Padding="{TemplateBinding Padding}" />
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
<!--Style and template for the DataGridColumnHeader.-->
<Style TargetType="{x:Type DataGridColumnHeader}">
<Setter Property="Background" Value="{DynamicResource NormalBorderBrush}"/>
<Setter Property="Foreground" Value="{DynamicResource TextBrush}"/>
<Setter Property="VerticalContentAlignment" Value="Center" />
<Setter Property="Height" Value="30"/>
<Setter Property="SeparatorBrush" Value="#FFC9CACA" />
<Setter Property="FontSize" Value="14"/>
<Setter Property="FontWeight" Value="SemiBold"/>
<Setter Property="Padding" Value="4 0 0 0"/>
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type DataGridColumnHeader}">
<ControlTemplate.Resources>
<Storyboard x:Key="HoverOn">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="Hover" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.2000000" Value="1"/>
</DoubleAnimationUsingKeyFrames>
</Storyboard>
<Storyboard x:Key="HoverOff">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="Hover" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.3000000" Value="0" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
</ControlTemplate.Resources>
<Grid Background='Transparent' >
<Grid.ColumnDefinitions>
<ColumnDefinition Width='Auto' />
<ColumnDefinition Width='Auto' />
<ColumnDefinition Width='*' />
<ColumnDefinition Width='Auto' />
</Grid.ColumnDefinitions>
<Rectangle x:Name="BackgroundRectangle" Grid.ColumnSpan="4" Grid.RowSpan="2"
Fill="{StaticResource NormalBrush}" Stretch="Fill" Stroke="{StaticResource NormalBorderBrush}" StrokeThickness="1" />
<Rectangle x:Name="Hover" Grid.ColumnSpan="4" Grid.RowSpan="2" Stretch="Fill"
Fill="{StaticResource MouseOverBrush}" Opacity="0" />
<ContentPresenter SnapsToDevicePixels="{TemplateBinding SnapsToDevicePixels}"
VerticalAlignment="{TemplateBinding VerticalContentAlignment}"
HorizontalAlignment="{TemplateBinding HorizontalContentAlignment}"
Margin='{TemplateBinding Padding}'
Cursor="{TemplateBinding Cursor}"/>
<Path HorizontalAlignment="Left" x:Name="SortArrow" VerticalAlignment="Center"
Width="8" Opacity="0" RenderTransformOrigin=".5,.5" Grid.Column="2" Grid.RowSpan="2" Fill="#FF000000" Stretch="Uniform" Data="F1 M -5.215,6.099L 5.215,6.099L 0,0L -5.215,6.099 Z ">
<Path.RenderTransform>
<TransformGroup>
<ScaleTransform ScaleX=".9" ScaleY=".9" x:Name="SortIconTransform" />
</TransformGroup>
</Path.RenderTransform>
</Path>
<Thumb x:Name="PART_LeftHeaderGripper" Grid.Column="0" HorizontalAlignment="Left" Style="{StaticResource ColumnHeaderGripperStyle}"/>
<Thumb x:Name="PART_RightHeaderGripper" Grid.Column="3" HorizontalAlignment="Right" Style="{StaticResource ColumnHeaderGripperStyle}"/>
</Grid>
<ControlTemplate.Triggers>
<Trigger Property="SortDirection" Value="Ascending">
<Setter TargetName="SortArrow" Property="Opacity" Value="1" />
<Setter TargetName="SortArrow" Property="RenderTransform">
<Setter.Value>
<RotateTransform Angle="180" />
</Setter.Value>
</Setter>
<Setter TargetName="BackgroundRectangle" Property="Opacity" Value="1" />
</Trigger>
<Trigger Property="SortDirection" Value="Descending">
<Setter TargetName="SortArrow" Property="Opacity" Value="1" />
<Setter TargetName="BackgroundRectangle" Property="Opacity" Value="1" />
</Trigger>
<Trigger Property="IsMouseOver" Value="true">
<Trigger.EnterActions>
<BeginStoryboard Storyboard="{StaticResource HoverOn}"/>
</Trigger.EnterActions>
<Trigger.ExitActions>
<BeginStoryboard Storyboard="{StaticResource HoverOff}"/>
</Trigger.ExitActions>
</Trigger>
</ControlTemplate.Triggers>
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
<!--Style and template for the DataGridColumnHeadersPresenter.-->
<Style TargetType="{x:Type DataGridColumnHeadersPresenter}">
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type DataGridColumnHeadersPresenter}">
<Grid>
<DataGridColumnHeader x:Name="PART_FillerColumnHeader" IsHitTestVisible="False" />
<ItemsPresenter />
</Grid>
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
<Style x:Key="{ComponentResourceKey ResourceId=DataGridSelectAllButtonStyle, TypeInTargetAssembly={x:Type DataGrid}}" TargetType="{x:Type Button}">
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type Button}">
<Grid>
<Rectangle x:Name="Border" Fill="{DynamicResource {x:Static SystemColors.ControlBrushKey}}" SnapsToDevicePixels="True"/>
<Polygon x:Name="Arrow" Fill="Black" HorizontalAlignment="Right" Margin="8,8,3,3" Opacity="0.15" Points="0,10 10,10 10,0" Stretch="Uniform" VerticalAlignment="Bottom"/>
</Grid>
<ControlTemplate.Triggers>
<Trigger Property="IsMouseOver" Value="True">
<Setter Property="Stroke" TargetName="Border" Value="{DynamicResource {x:Static SystemColors.ControlDarkBrushKey}}"/>
</Trigger>
<Trigger Property="IsPressed" Value="True">
<Setter Property="Fill" TargetName="Border" Value="{DynamicResource {x:Static SystemColors.ControlDarkBrushKey}}"/>
</Trigger>
<Trigger Property="IsEnabled" Value="False">
<Setter Property="Visibility" TargetName="Arrow" Value="Collapsed"/>
</Trigger>
</ControlTemplate.Triggers>
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
<Style TargetType="{x:Type DataGrid}">
<Setter Property="Background" Value="{StaticResource ControlContentBrush}"/>
<Setter Property="RowDetailsVisibilityMode" Value="VisibleWhenSelected"/>
<Setter Property="ScrollViewer.CanContentScroll" Value="true"/>
<Setter Property="ScrollViewer.PanningMode" Value="Both"/>
<Setter Property="Stylus.IsFlicksEnabled" Value="False"/>
<Setter Property="Margin" Value="5"/>
<Setter Property="BorderBrush" Value="{StaticResource NormalBorderBrush}" />
<Setter Property="AlternatingRowBackground" Value="{StaticResource AlternateBackgroundBrush}"/>
<Setter Property="HorizontalGridLinesBrush" Value="{StaticResource NormalBorderBrush}"/>
<Setter Property="VerticalGridLinesBrush" Value="{StaticResource NormalBorderBrush}"/>
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type DataGrid}">
<Border BorderBrush="{TemplateBinding BorderBrush}" BorderThickness="2" CornerRadius="5" Background="{TemplateBinding Background}" Padding="{TemplateBinding Padding}" SnapsToDevicePixels="True">
<ScrollViewer x:Name="DG_ScrollViewer" Focusable="false">
<ScrollViewer.Template>
<ControlTemplate TargetType="{x:Type ScrollViewer}">
<Grid>
<Grid.ColumnDefinitions>
<ColumnDefinition Width="Auto"/>
<ColumnDefinition Width="*"/>
<ColumnDefinition Width="Auto"/>
</Grid.ColumnDefinitions>
<Grid.RowDefinitions>
<RowDefinition Height="Auto"/>
<RowDefinition Height="*"/>
<RowDefinition Height="Auto"/>
</Grid.RowDefinitions>
<Button Command="{x:Static DataGrid.SelectAllCommand}" Focusable="false" Style="{DynamicResource {ComponentResourceKey ResourceId=DataGridSelectAllButtonStyle, TypeInTargetAssembly={x:Type DataGrid}}}" Visibility="{Binding HeadersVisibility, ConverterParameter={x:Static DataGridHeadersVisibility.All}, Converter={x:Static DataGrid.HeadersVisibilityConverter}, RelativeSource={RelativeSource AncestorType={x:Type DataGrid}}}" Width="{Binding CellsPanelHorizontalOffset, RelativeSource={RelativeSource AncestorType={x:Type DataGrid}}}"/>
<DataGridColumnHeadersPresenter x:Name="PART_ColumnHeadersPresenter" Grid.Column="1" Visibility="{Binding HeadersVisibility, ConverterParameter={x:Static DataGridHeadersVisibility.Column}, Converter={x:Static DataGrid.HeadersVisibilityConverter}, RelativeSource={RelativeSource AncestorType={x:Type DataGrid}}}"/>
<ScrollContentPresenter x:Name="PART_ScrollContentPresenter" CanContentScroll="{TemplateBinding CanContentScroll}" Grid.ColumnSpan="2" Grid.Row="1"/>
<ScrollBar x:Name="PART_VerticalScrollBar" Grid.Column="2" Maximum="{TemplateBinding ScrollableHeight}" Orientation="Vertical" Grid.Row="1" Visibility="{TemplateBinding ComputedVerticalScrollBarVisibility}" Value="{Binding VerticalOffset, Mode=OneWay, RelativeSource={RelativeSource TemplatedParent}}" ViewportSize="{TemplateBinding ViewportHeight}"/>
<Grid Grid.Column="1" Grid.Row="2">
<Grid.ColumnDefinitions>
<ColumnDefinition Width="{Binding NonFrozenColumnsViewportHorizontalOffset, RelativeSource={RelativeSource AncestorType={x:Type DataGrid}}}"/>
<ColumnDefinition Width="*"/>
</Grid.ColumnDefinitions>
<ScrollBar x:Name="PART_HorizontalScrollBar" Grid.Column="1" Maximum="{TemplateBinding ScrollableWidth}" Orientation="Horizontal" Visibility="{TemplateBinding ComputedHorizontalScrollBarVisibility}" Value="{Binding HorizontalOffset, Mode=OneWay, RelativeSource={RelativeSource TemplatedParent}}" ViewportSize="{TemplateBinding ViewportWidth}"/>
</Grid>
</Grid>
</ControlTemplate>
</ScrollViewer.Template>
<ItemsPresenter SnapsToDevicePixels="{TemplateBinding SnapsToDevicePixels}"/>
</ScrollViewer>
</Border>
</ControlTemplate>
</Setter.Value>
</Setter>
<Style.Triggers>
<Trigger Property="IsGrouping" Value="true">
<Setter Property="ScrollViewer.CanContentScroll" Value="false"/>
</Trigger>
</Style.Triggers>
</Style>
<Style TargetType="{x:Type DataGridRow}">
<Setter Property="SnapsToDevicePixels" Value="true"/>
<Setter Property="Validation.ErrorTemplate" Value="{x:Null}"/>
<Setter Property="ValidationErrorTemplate">
<Setter.Value>
<ControlTemplate>
<Grid>
<Ellipse Width="12" Height="12" Margin="0 2 0 0"
Fill="Red" Stroke="Black" VerticalAlignment="Top"
StrokeThickness="0.5"/>
<TextBlock FontWeight="Bold" Padding="4,0,0,0"
VerticalAlignment="Top" Foreground="White" Text="!"
ToolTip="{Binding (Validation.Errors)[0].ErrorContent, RelativeSource={RelativeSource FindAncestor, AncestorType={x:Type DataGridRow}}}"/>
</Grid>
</ControlTemplate>
</Setter.Value>
</Setter>
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type DataGridRow}">
<ControlTemplate.Resources>
<Storyboard x:Key="SelectedOn">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="select_gradient" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.1000000" Value="1" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
<Storyboard x:Key="SelectedOff">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="select_gradient" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.3000000" Value="0" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
<Storyboard x:Key="HoverOn">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="hover_gradient" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.1000000" Value="0.85" />
</DoubleAnimationUsingKeyFrames>
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="highlight" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.1000000" Value="0.65" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
<Storyboard x:Key="HoverOff">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="hover_gradient" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.3000000" Value="0" />
</DoubleAnimationUsingKeyFrames>
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="highlight" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.3000000" Value="0" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
</ControlTemplate.Resources>
<Border x:Name="DGR_Border" BorderBrush="{TemplateBinding BorderBrush}" BorderThickness="{TemplateBinding BorderThickness}" Background="{TemplateBinding Background}" SnapsToDevicePixels="True">
<SelectiveScrollingGrid>
<SelectiveScrollingGrid.ColumnDefinitions>
<ColumnDefinition Width="Auto"/>
<ColumnDefinition Width="*"/>
</SelectiveScrollingGrid.ColumnDefinitions>
<SelectiveScrollingGrid.RowDefinitions>
<RowDefinition Height="*"/>
<RowDefinition Height="Auto"/>
</SelectiveScrollingGrid.RowDefinitions>
<Rectangle x:Name="hover_gradient" Stroke="{DynamicResource FocusBrush}" StrokeThickness="1" RadiusX="1" RadiusY="1" Opacity="0" IsHitTestVisible="False" Grid.Column="1" Fill="{DynamicResource MouseOverBrush}"/>
<Rectangle x:Name="highlight" Margin="1" StrokeThickness="1" RadiusX="0.5" RadiusY="0.5" Opacity="0" IsHitTestVisible="False" Grid.Column="1" Stroke="{DynamicResource MouseOverHighlightBrush}" Fill="{DynamicResource MouseOverHighlightBrush}"/>
<Rectangle x:Name="select_gradient" Grid.Row="0" Grid.ColumnSpan="2" StrokeThickness="1" RadiusX="1" RadiusY="1" Opacity="0" IsHitTestVisible="False" Fill="{DynamicResource PressedBrush}" Stroke="{DynamicResource PressedBorderBrush}"/>
<DataGridCellsPresenter Grid.Column="1" ItemsPanel="{TemplateBinding ItemsPanel}" SnapsToDevicePixels="{TemplateBinding SnapsToDevicePixels}"/>
<DataGridDetailsPresenter Grid.Column="1" Grid.Row="1" SelectiveScrollingGrid.SelectiveScrollingOrientation="{Binding AreRowDetailsFrozen, ConverterParameter={x:Static SelectiveScrollingOrientation.Vertical}, Converter={x:Static DataGrid.RowDetailsScrollingConverter}, RelativeSource={RelativeSource AncestorType={x:Type DataGrid}}}" Visibility="{TemplateBinding DetailsVisibility}"/>
<DataGridRowHeader Grid.RowSpan="2" SelectiveScrollingGrid.SelectiveScrollingOrientation="Vertical" Visibility="{Binding HeadersVisibility, ConverterParameter={x:Static DataGridHeadersVisibility.Row}, Converter={x:Static DataGrid.HeadersVisibilityConverter}, RelativeSource={RelativeSource AncestorType={x:Type DataGrid}}}"/>
</SelectiveScrollingGrid>
</Border>
<ControlTemplate.Triggers>
<Trigger Property="IsMouseOver" Value="True" SourceName="DGR_Border">
<Trigger.ExitActions>
<BeginStoryboard Storyboard="{StaticResource HoverOff}" x:Name="HoverOff_BeginStoryboard" />
</Trigger.ExitActions>
<Trigger.EnterActions>
<BeginStoryboard Storyboard="{StaticResource HoverOn}" x:Name="HoverOn_BeginStoryboard" />
</Trigger.EnterActions>
</Trigger>
<Trigger Property="IsSelected" Value="true">
<Trigger.ExitActions>
<BeginStoryboard x:Name="SelectedOff_BeginStoryboard" Storyboard="{StaticResource SelectedOff}" />
</Trigger.ExitActions>
<Trigger.EnterActions>
<BeginStoryboard Storyboard="{StaticResource SelectedOn}" />
</Trigger.EnterActions>
</Trigger>
</ControlTemplate.Triggers>
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
<Style TargetType="{x:Type DataGridCell}">
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type DataGridCell}">
<ControlTemplate.Resources>
<Storyboard x:Key="SelectedOn">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="select_gradient" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.1000000" Value="1" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
<Storyboard x:Key="SelectedOff">
<DoubleAnimationUsingKeyFrames BeginTime="00:00:00" Storyboard.TargetName="select_gradient" Storyboard.TargetProperty="(UIElement.Opacity)">
<SplineDoubleKeyFrame KeyTime="00:00:00.3000000" Value="0" />
</DoubleAnimationUsingKeyFrames>
</Storyboard>
</ControlTemplate.Resources>
<Border BorderBrush="{TemplateBinding BorderBrush}" BorderThickness="{TemplateBinding BorderThickness}" Background="{TemplateBinding Background}" SnapsToDevicePixels="True">
<Grid>
<Rectangle x:Name="select_gradient" Margin="-2 -1 -2 -1" Grid.Column="1" StrokeThickness="1" RadiusX="1" RadiusY="1" Opacity="0" IsHitTestVisible="False" Fill="{DynamicResource PressedBrush}" Stroke="{DynamicResource PressedBorderBrush}"/>
<ContentPresenter SnapsToDevicePixels="{TemplateBinding SnapsToDevicePixels}"/>
</Grid>
</Border>
<ControlTemplate.Triggers>
<Trigger Property="IsSelected" Value="true">
<Trigger.ExitActions>
<BeginStoryboard x:Name="SelectedOff_BeginStoryboard" Storyboard="{StaticResource SelectedOff}" />
</Trigger.ExitActions>
<Trigger.EnterActions>
<BeginStoryboard Storyboard="{StaticResource SelectedOn}" />
</Trigger.EnterActions>
</Trigger>
</ControlTemplate.Triggers>
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
<BooleanToVisibilityConverter x:Key="bool2VisibilityConverter"/>
<Style x:Key="RowHeaderGripperStyle" TargetType="{x:Type Thumb}">
<Setter Property="Height" Value="8"/>
<Setter Property="Background" Value="Transparent"/>
<Setter Property="Cursor" Value="SizeNS"/>
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type Thumb}">
<Border Background="{TemplateBinding Background}" Padding="{TemplateBinding Padding}"/>
</ControlTemplate>
</Setter.Value>
</Setter>
</Style>
<Style TargetType="{x:Type DataGridRowHeader}">
<Setter Property="Width" Value="20"/>
<Setter Property="Template">
<Setter.Value>
<ControlTemplate TargetType="{x:Type DataGridRowHeader}">
<Grid>
<Microsoft_Windows_Themes:DataGridHeaderBorder BorderBrush="{TemplateBinding BorderBrush}" BorderThickness="{TemplateBinding BorderThickness}" Background="{TemplateBinding Background}" IsPressed="{TemplateBinding IsPressed}" IsHovered="{TemplateBinding IsMouseOver}" IsSelected="{TemplateBinding IsRowSelected}" Orientation="Horizontal" Padding="{TemplateBinding Padding}" SeparatorBrush="{TemplateBinding SeparatorBrush}" SeparatorVisibility="{TemplateBinding SeparatorVisibility}">
<StackPanel Orientation="Horizontal">
<ContentPresenter SnapsToDevicePixels="{TemplateBinding SnapsToDevicePixels}" VerticalAlignment="Center"/>
<Control SnapsToDevicePixels="false" Template="{Binding ValidationErrorTemplate, RelativeSource={RelativeSource AncestorType={x:Type DataGridRow}}}" Visibility="{Binding (Validation.HasError), Converter={StaticResource bool2VisibilityConverter}, RelativeSource={RelativeSource AncestorType={x:Type DataGridRow}}}"/>
</StackPanel>
</Microsoft_Windows_Themes:DataGridHeaderBorder>
<Thumb x:Name="PART_TopHeaderGripper" Style="{StaticResource RowHeaderGripperStyle}" VerticalAlignment="Top"/>
<Thumb x:Name="PART_BottomHeaderGripper" Style="{StaticResource RowHeaderGripperStyle}" VerticalAlignment="Bottom"/>
</Grid>
</ControlTemplate>
</Setter.Value>
