Creating Custom ListView In Xamarin Android App

Virendra Thakur
7y
23.7k
0
7

100

Article

Introduction

In this article, we are going to learn about how to create a custom ListView in Xamarin Android app.

Solution

Here are the steps to add tabs in an Android app.

Step 1

Create/ open your Android solution in Visual Studio or Xamarin Studio.

Step 2

Create the ListView inside your AXML file, as shown below.

(File Name: main.axml)

<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="vertical"
android:layout_width="match_parent"
android:layout_height="match_parent">
<ListView
android:id="@+id/listView"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:fastScrollEnabled="true" />
</LinearLayout>

Step 3: Initialize ListView in MainActivity, as shown below.

(File Name: MainActivity.cs)

public class MainActivity : Activity
{
//Intialize ListView
ListView myList;
protected override void OnCreate(Bundle bundle)
{
base.OnCreate(bundle);
// Set our view from the "main" layout resource
SetContentView(Resource.Layout.Main);
myList = FindViewById<ListView>(Resource.Id.listView);
}
}

Step 4

Now, create the row for the ListView cell to show the details of the user as Name, Image and Department.

(FileName: userRow.axml)

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
android:orientation="horizontal"
android:layout_width="fill_parent"
android:layout_height="fill_parent"
android:minWidth="25px"
android:minHeight="25px"
android:paddingBottom="4dp">
<ImageView
android:id="@+id/photoImageView"
android:layout_width="60dp"
android:layout_height="60dp"
android:layout_alignParentLeft="true"
android:layout_centerVertical="true"
android:padding="5dp" />
<TextView
android:id="@+id/nameTextView"
android:layout_toRightOf="@id/photoImageView"
android:text="Name"
android:textAppearance="?android:attr/textAppearanceLarge"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:paddingLeft="5dp" />
<TextView
android:id="@+id/departmentTextView"
android:layout_toRightOf="@id/photoImageView"
android:layout_below="@id/nameTextView"
android:text="Department"
android:textAppearance="?android:attr/textAppearanceSmall"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:paddingLeft="5dp" />
</RelativeLayout>

Step 5

Create User Model, as shown below.

(File Name: User.cs)

public class User
{
public string Name { get; set; }
public string ImageUrl { get; set; }
public string Department { get; set; }
public string Details { get; set; }
public override string ToString()
{
return Name + " " + Department;
}
}

Step 6

To bind the row, we required ListView Adapter, so create a Custom Adapter, as shown below.

(File Name: MyCustomListAdapter.cs)

public class MyCustomListAdapter : BaseAdapter<User>
{
List<User> users;
public MyCustomListAdapter(List<User> users)
{
this.users = users;
}
public override User this[int position]
{
get
{
return users[position];
}
}
public override int Count
{
get
{
return users.Count;
}
}
public override long GetItemId(int position)
{
return position;
}
public override View GetView(int position, View convertView, ViewGroup parent)
{
var view = convertView;
if(view==null)
{
view = LayoutInflater.From(parent.Context).Inflate(Resource.Layout.userRow, parent, false);
var photo = view.FindViewById<ImageView>(Resource.Id.photoImageView);
var name = view.FindViewById<TextView>(Resource.Id.nameTextView);
var department = view.FindViewById<TextView>(Resource.Id.departmentTextView);
view.Tag = new ViewHolder() { Photo = photo, Name = name, Department = department };
}
var holder = (ViewHolder)view.Tag;
holder.Photo.SetImageDrawable(ImageManager.Get(parent.Context, users[position].ImageUrl));
holder.Name.Text = users[position].Name;
holder.Department.Text = users[position].Department;
return view;
}
}

The Custom Adapter is extended by the Base Adapter and it has some Abstract methods, as shown below.

Count- This method returns the count of the list items.
GetItemId- It returns the position of the item.
GetView- This method is used to bind the view to the ListView row, it will bind the data with the row.

Step 7

Now, create the Image Manager class, which is used to bind the images with the ImageView, as shown below.

(File Name: ImageManager.cs)

public static class ImageManager
{
static Dictionary<string, Drawable> cache = new Dictionary<string, Drawable>();
public static Drawable Get(Context context, string url)
{
if (!cache.ContainsKey(url))
{
var drawable = Drawable.CreateFromStream(context.Assets.Open(url), null);
cache.Add(url, drawable);
}
return cache[url];
}
}

In the code given above, the images are boud with the Assets folder. (Add the images to the Image folder accordingly).

Step 8

Now, we require data source for the list, so we will create UserData file to provide the data to the list, as shown below.

(File Name: UserData.cs)

public static class UserData
{
public static List<User> Users { get; private set; }
static UserData()
{
var temp = new List<User>();
AddUser(temp);
AddUser(temp);
AddUser(temp);
Users = temp.OrderBy(i => i.Name).ToList();
}
static void AddUser(List<User> users)
{
users.Add(new User()
{
Name = "aVirendra Thakur",
Department = "Xamarin Android & Xamarin Forms Development",
ImageUrl = "images/image.png",
Details = "Virendra has over 2 years of experience developing mobile applications,"
});
users.Add(new User()
{
Name = "bVirendra Thakur",
Department = "Xamarin Android & Xamarin Forms Development",
ImageUrl = "images/image2.png",
Details = "Virndra has over 2 years of experience developing mobile applications; specializing in Android & C# cross platform development."
});
users.Add(new User()
{
Name = "bVirendra Thakur",
Department = "Xamarin Android & Xamarin Forms Development",
ImageUrl = "images/image.png",
Details = "Virndra has over 2 years of experience developing mobile applications; specializing in Android & C# cross platform development."
});
users.Add(new User()
{
Name = "aVirendra Thakur",
Department = "Xamarin Android & Xamarin Forms Development",
ImageUrl = "images/image2.png",
Details = "Virndra has over 2 years of experience developing mobile applications; specializing in Android & C# cross platform development."
}); users.Add(new User()
{
Name = "dVirendra Thakur",
Department = "Xamarin Android & Xamarin Forms Development",
ImageUrl = "images/image.png",
Details = "Virndra has over 2 years of experience developing mobile applications; specializing in Android & C# cross platform development."
});
}

Step 9

Create ViewHolder Class, which holds the controls of the view. It will only create the controls and reuse it in ListView, which saves the memory.

(File Name: ViewHolder.cs)

public class ViewHolder: Java.Lang.Object
{
public ImageView Photo { get; set; }
public TextView Name { get; set; }
public TextView Department { get; set; }
}

Step 10

Now, go to MyCustomListAdapter and add the few lines of code to bind the data, as shown below.

(File Name: MyCustomListAdapter.cs)

public override View GetView(int position, View convertView, ViewGroup parent)
{
var view = convertView;
if(view==null)
{
view = LayoutInflater.From(parent.Context).Inflate(Resource.Layout.userRow, parent, false);
var photo = view.FindViewById<ImageView>(Resource.Id.photoImageView);
var name = view.FindViewById<TextView>(Resource.Id.nameTextView);
var department = view.FindViewById<TextView>(Resource.Id.departmentTextView);
view.Tag = new ViewHolder() { Photo = photo, Name = name, Department = department };
}
var holder = (ViewHolder)view.Tag;
holder.Photo.SetImageDrawable(ImageManager.Get(parent.Context, users[position].ImageUrl));
holder.Name.Text = users[position].Name;
holder.Department.Text = users[position].Department;
return view;
}
