Serialization -DeSerialization of Windows Form in C#

Pritish Deshmukh
12y
20.4k
0
0

Blog

SerializationWithWINForm.zip


using System;

using System.Collections.Generic;

using System.Linq;

using System.Text;
using System.Runtime.Serialization;
using System.IO;
using System.Runtime.Serialization.Formatters.Binary;

namespace SerializationWithWINForm
{
    [Serializable]
    public class SerializeProp
    {

        private int _id;
        private int _number;
        private string _empname = string.Empty;
        private string _address = string.Empty;
        public SerializeProp()
        {
        }
        public int ID
        {
            get
            {
                return _id;
            }
            set
            {
                _id = value;
            }
        }

        public int Number
        {
            get
            {
                return _number;
            }
            set
            {
                _number = value;
            }
        }
        public string Address
        {
            get
            {
                return _address;
            }
            set
            {
                _address = value;
            }
        }
        public string EmpName
        {
            get
            {
                return _empname;
            }
            set
            {
                _empname = value;
            }
        }

    }
}

 using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Data;
using System.Drawing;
using System.Linq;
using System.Text;
using System.Windows.Forms;
using System.IO;
using System.Runtime.Serialization;
using System.Runtime.Serialization.Formatters;
using System.Runtime.Serialization.Formatters.Binary;

namespace SerializationWithWINForm
{

    public partial class SerializeForm :Form
    {
        public SerializeForm()
        {
            InitializeComponent();
        }
        SerializeProp objISerializeProp = new SerializeProp();
        IFormatter objBinaryFormatter = new BinaryFormatter();
        private string _filePath = "C:\\WinFormSerializeLog.txt";

        private void button1_Click(object sender, EventArgs e)
        {
            objISerializeProp.ID = Convert.ToInt32(txtID.Text);
            objISerializeProp.EmpName = txtName.Text;
            objISerializeProp.Number = Convert.ToInt32(txtNumber.Text);
            objISerializeProp.Address = txtAddress.Text;
        }

        private void button2_Click(object sender, EventArgs e)
        {

            Stream objStream = new FileStream(_filePath,
                               FileMode.Create,
                               FileAccess.ReadWrite,
                               FileShare.None);

            objISerializeProp.ID = objISerializeProp.ID;
            objISerializeProp.EmpName = objISerializeProp.EmpName;
            objISerializeProp.Number = objISerializeProp.Number;
            objISerializeProp.Address = objISerializeProp.Address;

            objBinaryFormatter.Serialize(objStream, objISerializeProp);
            objStream.Close();
            txtID.Text = "";
            txtName.Text = "";
            txtNumber.Text = "";
            txtAddress.Text = "";
        }

        private void SerializeForm_Load(object sender, EventArgs e)
        {
            Stream objStreamDeSerialize = new FileStream(_filePath,
                               FileMode.Open,
                               FileAccess.Read,
                               FileShare.Read);

            objISerializeProp = (SerializeProp)objBinaryFormatter.Deserialize(objStreamDeSerialize);
            txtID.Text = objISerializeProp.ID.ToString();
            txtName.Text = objISerializeProp.EmpName;
            txtNumber.Text = objISerializeProp.Number.ToString();
            txtAddress.Text = objISerializeProp.Address;
            objStreamDeSerialize.Close();
        }

        private void button3_Click(object sender, EventArgs e)
        {
            txtID.Text = "";
            txtName.Text = "";
            txtNumber.Text = "";
            txtAddress.Text = "";
        }
    }
}

namespace SerializationWithWINForm

{

partial class SerializeForm

{

/// <summary>

/// Required designer variable.

/// </summary>

private System.ComponentModel.IContainer components = null;

/// <summary>

/// Clean up any resources being used.

/// </summary>

/// <param name="disposing">true if managed resources should be disposed; otherwise, false.</param>

protected override void Dispose(bool disposing)

{

if (disposing && (components != null))

{

components.Dispose();

}

base.Dispose(disposing);

}

#region Windows Form Designer generated code

/// <summary>

/// Required method for Designer support - do not modify

/// the contents of this method with the code editor.

/// </summary>

private void InitializeComponent()

{

this.button1 = new System.Windows.Forms.Button();

this.button2 = new System.Windows.Forms.Button();

this.txtID = new System.Windows.Forms.TextBox();

this.txtName = new System.Windows.Forms.TextBox();

this.txtNumber = new System.Windows.Forms.TextBox();

this.txtAddress = new System.Windows.Forms.TextBox();

this.label1 = new System.Windows.Forms.Label();

this.label2 = new System.Windows.Forms.Label();

this.label3 = new System.Windows.Forms.Label();

this.label4 = new System.Windows.Forms.Label();

this.button3 = new System.Windows.Forms.Button();

this.SuspendLayout();

// button1

this.button1.Location = new System.Drawing.Point(12, 204);

this.button1.Name = "button1";

this.button1.Size = new System.Drawing.Size(75, 23);

this.button1.TabIndex = 0;

this.button1.Text = "ok";

this.button1.UseVisualStyleBackColor = true;

this.button1.Click += new System.EventHandler(this.button1_Click);

// button2

this.button2.Location = new System.Drawing.Point(93, 204);

this.button2.Name = "button2";

this.button2.Size = new System.Drawing.Size(75, 23);

this.button2.TabIndex = 1;

this.button2.Text = "Serialize";

this.button2.UseVisualStyleBackColor = true;

this.button2.Click += new System.EventHandler(this.button2_Click);

// txtID

this.txtID.Location = new System.Drawing.Point(181, 13);

this.txtID.Name = "txtID";

this.txtID.Size = new System.Drawing.Size(100, 20);

this.txtID.TabIndex = 2;

// txtName

this.txtName.Location = new System.Drawing.Point(181, 54);

this.txtName.Name = "txtName";

this.txtName.Size = new System.Drawing.Size(100, 20);

this.txtName.TabIndex = 3;

// txtNumber

this.txtNumber.Location = new System.Drawing.Point(181, 102);

this.txtNumber.Name = "txtNumber";

this.txtNumber.Size = new System.Drawing.Size(100, 20);

this.txtNumber.TabIndex = 4;

// txtAddress

this.txtAddress.Location = new System.Drawing.Point(181, 152);

this.txtAddress.Name = "txtAddress";

this.txtAddress.Size = new System.Drawing.Size(100, 20);

this.txtAddress.TabIndex = 5;

// label1

this.label1.AutoSize = true;

this.label1.Location = new System.Drawing.Point(36, 19);

this.label1.Name = "label1";

this.label1.Size = new System.Drawing.Size(18, 13);

this.label1.TabIndex = 6;

this.label1.Text = "ID";

// label2

this.label2.AutoSize = true;

this.label2.Location = new System.Drawing.Point(39, 60);

this.label2.Name = "label2";

this.label2.Size = new System.Drawing.Size(35, 13);

this.label2.TabIndex = 7;

this.label2.Text = "Name";

// label3

this.label3.AutoSize = true;

this.label3.Location = new System.Drawing.Point(39, 108);

this.label3.Name = "label3";

this.label3.Size = new System.Drawing.Size(44, 13);

this.label3.TabIndex = 8;

this.label3.Text = "Number";

// label4

this.label4.AutoSize = true;

this.label4.Location = new System.Drawing.Point(42, 158);

this.label4.Name = "label4";

this.label4.Size = new System.Drawing.Size(45, 13);

this.label4.TabIndex = 9;

this.label4.Text = "Address";

// button3

this.button3.Location = new System.Drawing.Point(174, 204);

this.button3.Name = "button3";

this.button3.Size = new System.Drawing.Size(75, 23);

this.button3.TabIndex = 10;

this.button3.Text = "Clear";

this.button3.UseVisualStyleBackColor = true;

this.button3.Click += new System.EventHandler(this.button3_Click);

// SerializeForm

this.AutoScaleDimensions = new System.Drawing.SizeF(6F, 13F);

this.AutoScaleMode = System.Windows.Forms.AutoScaleMode.Font;

this.ClientSize = new System.Drawing.Size(292, 266);

this.Controls.Add(this.button3);

this.Controls.Add(this.label4);

this.Controls.Add(this.label3);

this.Controls.Add(this.label2);

this.Controls.Add(this.label1);

this.Controls.Add(this.txtAddress);

this.Controls.Add(this.txtNumber);

this.Controls.Add(this.txtName);

this.Controls.Add(this.txtID);

this.Controls.Add(this.button2);

this.Controls.Add(this.button1);

this.Name = "SerializeForm";

this.Text = "Form1";

this.Load += new System.EventHandler(this.SerializeForm_Load);

this.ResumeLayout(false);

this.PerformLayout();

}

#endregion

private System.Windows.Forms.Button button1;

private System.Windows.Forms.Button button2;

private System.Windows.Forms.TextBox txtID;

private System.Windows.Forms.TextBox txtName;

private System.Windows.Forms.TextBox txtNumber;

private System.Windows.Forms.TextBox txtAddress;

private System.Windows.Forms.Label label1;

private System.Windows.Forms.Label label2;

private System.Windows.Forms.Label label3;

private System.Windows.Forms.Label label4;

private System.Windows.Forms.Button button3;

}
