.NET

PDF Viewer Using FlexPaper

About FlexPaper

Flexpaper is an open-source web-based document viewer.
Link : Devaldi

It provides an efficient and fancy way to view a PDF.
The complete version of the code is available at [ Zine Servertrial ].
It must be configured as well as all the standalone exe's used must be downloaded.

Minimizing the Code

I minimized and deleted all the files except what I needed for viewing the PDF.

Tools Used

  1. Flexpaper Asset Files (Images for toolbar and the UI).
  2. Pdf2json.exe (Converting pdf config to a JSON string).
  3. Mudraw.exe (Converting pdf page to Image).
  4. Pdftk.exe (Splitting the PDF).

I removed the Configuration Files from the original source and added a class called PDFProcess.cs to do the required process of viewing the PDF.

The website Structure



The Startup File [simple_document.aspx]

  1. <%@ Page Language="C#" AutoEventWireup="true" CodeFile="simple_document.aspx.cs"
  2. Inherits="simple_document" %>
  3. <!doctype html><html><head><meta http-equiv="Content-Type" content="text/html; charset=utf-8" /><meta name="viewport" content="initial-scale=1,user-scalable=0,maximum-scale=1,width=device-width" /><style type="text/css" media="screen">
  4. html, body { height:100%; }
  5. body { margin:0; padding:0; overflow:auto; }
  6. #flashContent { display:none; }
  7. </style><link rel="stylesheet" type="text/css" href="css/flexpaper.css?r53556" /><script type="text/javascript" src="js/jquery.min.js?r53556"></script><script type="text/javascript" src="js/jquery.extensions.min.js?r53556"></script><script type="text/javascript" src="js/flexpaper.js?r53556"></script><script type="text/javascript" src="js/flexpaper_handlers.js?r53556"></script></head><body><div id="documentViewer" class="flexpaper_viewer" style="position:absolute;;width:100%;height:100%;background-color:#222222;;"></div><script type="text/javascript">
  8. $('#documentViewer').FlexPaperViewer(
  9. {
  10. config:
  11. {
  12. IMGFiles: "<% =IMGFilesPath %>",
  13. JSONFile: "<% =JSONFilePath %>",
  14. PDFFile: "<% =PDFFilePath %>",
  15. Scale: 0.6,
  16. ZoomTransition: 'easeOut',
  17. ZoomTime: 0.4,
  18. ZoomInterval: 0.1,
  19. FitPageOnLoad: true,
  20. FitWidthOnLoad: false,
  21. AutoAdjustPrintSize: true,
  22. PrintPaperAsBitmap: false,
  23. AutoDetectLinks: false,
  24. FullScreenAsMaxWindow: true,
  25. ProgressiveLoading: false,
  26. MinZoomSize: 0.3,
  27. MaxZoomSize: 5,
  28. SearchMatchAll: true,
  29. InitViewMode: 'Portrait',
  30. RenderingOrder: 'html5,html5',
  31. StartAtPage: 1,
  32. MixedMode: true,
  33. EnableWebGL: false,
  34. PublicationTitle: '',
  35. ViewModeToolsVisible: true,
  36. ZoomToolsVisible: true,
  37. NavToolsVisible: true,
  38. CursorToolsVisible: true,
  39. SearchToolsVisible: true,
  40. UIConfig: 'UIConfig.xml?r53556',
  41. WMode: 'transparent',
  42. key: '#V2ZzfWBFX1pcQRhwB0lFXlVeYw',
  43. localeChain: 'en_US'
  44. }
  45. }
  46. );
[simple_document.aspx.cs]
  1. using System;
  2. using System.Collections.Generic;
  3. using System.IO;
  4. using System.Linq;
  5. using System.Web;
  6. using System.Web.UI;
  7. using System.Web.UI.WebControls;
  8. public partial class simple_document: System.Web.UI.Page
  9. {
  10.     public string IMGFilesPath = "";
  11.     public string JSONFilePath = "";
  12.     public string PDFFilePath = "";
  13.     protected void Page_Load(object sender, EventArgs e)
  14.     {
  15.         // Set the Docs Path where the processed files will be stored
  16.         string uploadFolderAbsPath = Server.MapPath("~/docs/");
  17.         string uploadFolderRelPath = ResolveUrl("~/docs/");
  18.         // Set the PDF Source Path and filename
  19.         string sourceFilePath = Server.MapPath("~/pdf/");
  20.         string sourceFileName = "Paper.pdf";
  21.         IMGFilesPath = uploadFolderRelPath + sourceFileName + "_{page}.png";
  22.         JSONFilePath = uploadFolderRelPath + sourceFileName + ".js";
  23.         PDFFilePath = uploadFolderRelPath + Path.GetFileNameWithoutExtension(sourceFileName) + "_[*,0].pdf";
  24.         PDFProcess pdfProcess = new PDFProcess();
  25.         //Convert PDF to Images
  26.         pdfProcess.PDF2Image(uploadFolderAbsPath, sourceFilePath, sourceFileName);
  27.         //Convert PDF to JSON
  28.         pdfProcess.PDF2JSON(uploadFolderAbsPath, sourceFilePath, sourceFileName);
  29.         // Split PDF Pages
  30.         pdfProcess.SplitPDF(uploadFolderAbsPath, sourceFilePath, sourceFileName);
  31.     }
  32. }
The main processing Class [PDFProcess.cs]
  1. using System;
  2. using System.Collections.Generic;
  3. using System.Linq;
  4. using System.Web;
  5. using System.IO;
  6. /// <summary>
  7. /// Summary description for PDF2Image
  8. /// </summary>
  9. public class PDFProcess
  10. {
  11.     public int PDF2Image(string uploadFolder, string sourceFilePath, string sourceFileName) {
  12.         System.Diagnostics.Process proc = new System.Diagnostics.Process();
  13.         proc.StartInfo.FileName = HttpContext.Current.Server.MapPath("~/bin/mudraw.exe");
  14.         proc.StartInfo.UseShellExecute = false;
  15.         proc.StartInfo.WindowStyle = System.Diagnostics.ProcessWindowStyle.Hidden;
  16.         proc.StartInfo.CreateNoWindow = true;
  17.         proc.StartInfo.Arguments = "-r100 -o " + "\"" + uploadFolder + sourceFileName + "_%d.png\" " + "\"" + sourceFilePath + sourceFileName + "\"";
  18.         if (proc.Start())
  19.         {
  20.             proc.WaitForExit();
  21.             proc.Close();
  22.             return 1;
  23.         } else return 2;
  24.     }
  25.     public int PDF2JSON(string uploadFolder, string sourceFilePath, string sourceFileName) {
  26.         System.Diagnostics.Process proc = new System.Diagnostics.Process();
  27.         proc.StartInfo.FileName = HttpContext.Current.Server.MapPath("~/bin/pdf2json.exe");
  28.         proc.StartInfo.UseShellExecute = false;
  29.         proc.StartInfo.WindowStyle = System.Diagnostics.ProcessWindowStyle.Hidden;
  30.         proc.StartInfo.CreateNoWindow = true;
  31.         proc.StartInfo.Arguments = "\"" + sourceFilePath + sourceFileName + "\" -enc UTF-8 -compress " + "\"" + uploadFolder + sourceFileName + ".js" + "\"";
  32.         if (proc.Start())
  33.         {
  34.             proc.WaitForExit();
  35.             proc.Close();
  36.             return 1;
  37.         } else return 2;
  38.
  39.     }
  40.     public int SplitPDF(string uploadFolder, string sourceFilePath, string sourceFileName) {
  41.         System.Diagnostics.Process proc = new System.Diagnostics.Process();
  42.         proc.StartInfo.FileName = HttpContext.Current.Server.MapPath("~/bin/pdftk.exe");
  43.         proc.StartInfo.UseShellExecute = false;
  44.         proc.StartInfo.WindowStyle = System.Diagnostics.ProcessWindowStyle.Hidden;
  45.         proc.StartInfo.CreateNoWindow = true;
  46.         proc.StartInfo.Arguments = "\"" + sourceFilePath + sourceFileName + "\" burst output " + "\"" + uploadFolder + Path.GetFileNameWithoutExtension(sourceFileName) + "_%1d.pdf" + "\" compress";
  47.         if (proc.Start())
  48.         {
  49.             proc.WaitForExit();
  50.             proc.Close();
  51.             return 1;
  52.         } else return 2;
  53.     }
  54. }
The output



Using the Source Code

Download the source code and open as a Web Site. Set the [simple_document.aspx] as the Startup File and run.
